8-10 Electromagnetic Compatibility (EMC) Rexroth IndraDrive
DOK-INDRV*-SYSTEM*****-PR02-EN-P
Limit Value Classes for HMV01.1R Supply Modules
Note: Damage caused by missing mains choke! Always operate
HMV01.1R supply units with the assigned mains choke
HNL01.1R.
Supply unit type Mains filter type Max. allowed
number of
drive contr.
Max. allowed
total length of
motor cable
[ m ]
PWM
frequ.
[kHz]
Allowed leakage
capacitance to comply
with limit value class
[ nF ]
assigned mains choke HNL01.1R required
HMS01;
HMD01
A2.1 A2.2 A1 B1
HMV01.1R-W0018 HNF01.1A-F240-R0026 12
280
110
4
8
12
16
tbd 290 290 -
HMV01.1R-W0018 HNF01.1A-M900-R0026 22
1050
270
4
8
12
16
tbd 1100 1100 -
HMV01.1R-W0045 HNF01.1A-F240-R0065 12
280
110
4
8
12
16
tbd 290 290 -
HMV01.1R-W0045 HNF01.1A-M900-R0065 22
1050
270
4
8
12
16
tbd 1100 1100 -
HMV01.1R-W0065 HNF01.1A-F240-R0094 12
280
110
4
8
12
16
tbd 290 - -
HMV01.1R-W0065 HNF01.1A-M900-R0094 22
1050
270
4
8
12
16
tbd 1100 - -
tbd in preparation
Fig. 8-7: Supply modules HMV01.1R with / without mains filter HNF
