cobas p 512 Part D - Maintenance
Operator's Manual - Version 1.6 - 09/2015 4-9
Figure 4-3: Inner view of decapper module
A
Connecting piece for cylinder
C
Funnel
B
Knurled screws
6. Loosen the connecting pieces on the cap-removal cylinder.
NOTICE
Hold on tight to the connecting pieces. When loosening, compressed air can escape!
7. Loosen the knurled screws. It is sufficient to only loosen the knurled screws.
8. Pull out the cap removal device upwards.
9. Unscrew the knurled screw of the funnel and lift it out.
C
B
A
