Roche Diagnostics
Operator’s Manual · Version 3.0 109
Multiplate® analyzer 5 Operation
Performing a measurement
Ensure that the magnetic stirrer is inside the test cell and rotates. If the magnetic
stirrer does not rotate, lock the affected channel and contact your Roche Service
representative.
u See Lock/unlock channels (p. 76).
7
Connect the sensor cable(s) to the test cell(s).
Figure 5-12 Connecting test cells
o Squeeze the rear part of the front plug to loosen it and pull the sensor cable out
of its parking position.
o Push it gently into the jack area of the test cell. The plug should snap firmly
into the test cell.
8
Choose the Start pipetting program button.
Only those channels are started which are assigned to an order.
The Process mea surement series window is displayed.
Figure 5-13 Process measurement series window
The right part of the window explains basic pipette operating instructions. The
lower part shows the pipette steps for each channel. An arrow indicates the
current pipette step (B). Subsequent steps are marked with a dot, executed steps
with a tick.
The Pipetting instruction panel (A) contains instructions on how to proceed.
A
B
