COMMAND RANGING & TELEMETRY UNIT CORTEX
CRT QUANTUM USER'S MANUAL
Ref. DTU 100042
Is.Rev. 5.17
Date: Dec.
03, 2021Sept. 30, 2021
© Safran Data Systems
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 197
register 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 Output
time
0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
1 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 Epoch
2 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
3 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
4 1 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
5 1 1 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1
6 1 1 1 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1
7 0 1 1 1 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1
8 0 0 1 1 1 0 0 0 1 1 1 1 1 1 1 1 1 1 1
9 1 0 0 1 1 1 0 0 0 1 1 1 1 1 1 1 1 1 1
10 1 1 0 0 1 1 1 0 0 0 1 1 1 1 1 1 1 1 1
11 1 1 1 0 0 1 1 1 0 0 0 1 1 1 1 1 1 1 1
12 1 1 1 1 0 0 1 1 1 0 0 0 1 1 1 1 1 1 1
13 0 1 1 1 1 0 0 1 1 1 0 0 0 1 1 1 1 1 1
14 0 0 1 1 1 1 0 0 1 1 1 0 0 0 1 1 1 1 1
15 1 0 0 1 1 1 1 0 0 1 1 1 0 0 0 1 1 1 1
16 1 1 0 0 1 1 1 1 0 0 1 1 1 0 0 0 1 1 1
17 0 1 1 0 0 1 1 1 1 0 0 1 1 1 0 0 0 1 1
18 0 0 1 1 0 0 1 1 1 1 0 0 1 1 1 0 0 0 1
19 1 0 0 1 1 0 0 1 1 1 1 0 0 1 1 1 0 0 0
20 0 1 0 0 1 1 0 0 1 1 1 1 0 0 1 1 1 0 0
21 1 0 1 0 0 1 1 0 0 1 1 1 1 0 0 1 1 1 0
22 0 1 0 1 0 0 1 1 0 0 1 1 1 1 0 0 1 1 1
23 0 0 1 0 1 0 0 1 1 0 0 1 1 1 1 0 0 1 1
24 0 0 0 1 0 1 0 0 1 1 0 0 1 1 1 1 0 0 1
25 1 0 0 0 1 0 1 0 0 1 1 0 0 1 1 1 1 0 0
Epoch corresponds to the first of the 18 ‘1’ that precedes the first ‘0’ of the sequence.
At the final signal level, one must define precisely what the Epoch position is. For instance, when RRC filtering is
involved, the first stage of processing consists in interpolating with zero insertion the sequence by an integer
factor of K and then the RRC filtering proper is applied:
