Epoch position after interpolation by zero insertion
Epoch position after RRC filtering
SQPN Q code signal and Epoch position
First chip of sequence = Epoch of the sequence
Last chip of sequence
The Epoch position is the midpoint between the last and the first chip of the sequence.
When the last and first chip are different, this corresponds to the zero crossing.
SQPN Q code signal
baseband PM signal (real part / sine )
Zero crossing of both signals
