2.3.2. I/O Connectors description
2.3.2.1. External interconnection panel
The connectors are described based on the groups of functions highlighted by lines and a general label on the interconnection panels.
For any signal, all characteristics and labels are identical whatever chassis is supplied.
CONNECTOR
TYPE
CONNECTOR
PANEL
LABEL
CABLE
SLEEVE
LABEL
MSP MODULE
CONNECTOR
LABEL
SIGNAL
ELECTRICAL CHARACTERISTICS
UPLINK
BNC Female
NOMINAL IF
1
UL NOM IF1
IF out
NOM 1
IFM-1 Nominal IF output port
50-90 MHz (-3 dB bandwidth)
0 to - 80 dBm, 50 
BNC Female
ALTERNATE IF
1
UL ALT IF1
IF out
ALT 1
IFM-1 Alternate IF output port
DC-90 MHz (-3 dB bandwidth)
- 20 dBm, 50 
BNC Female
NOMINAL IF
2
UL NOM IF2
IF out
NOM 2
IFM-2 Nominal IF output port
50-90 MHz (-3 dB bandwidth)
0 to - 80 dBm, 50 
BNC Female
ALTERNATE IF
2
UL ALT IF2
IF out
ALT 2
IFM-2 Alternate IF output port
DC-90 MHz (-3 dB bandwidth)
- 20 dBm, 50 
BNC Female
VIDEO IN
1
UL VIDEO IN1
Note 1
Auxiliary video input to IFM-1
(analog signal)
100 Hz - 2 MHz
2 Vpp - 50 
BNC Female
VIDEO IN
2
UL VIDEO IN2
Note 1
Auxiliary video input to IFM-2
(analog signal)
100 Hz - 2 MHz
2 Vpp - 50 
