CONNECTOR
TYPE
CONNECTOR
PANEL
LABEL
CABLE
SLEEVE
LABEL
MSP MODULE
CONNECTOR
LABEL
SIGNAL
ELECTRICAL CHARACTERISTICS
DOWNLINK
BNC Female
NOMINAL IF
1
DL NOM IF1
IF in
NOM 1
Nominal IF input port # 1
45-95 MHz (-3 dB bandwidth)
-15 to -120 dBm, 50 
BNC Female
ALTERNATE IF
1
DL ALT IF1
IF in
ALT 1
Alternate IF input port # 1
45-95 MHz (-3 dB bandwidth)
-15 to -120 dBm, 50 
BNC Female
NOMINAL IF
2
DL NOM IF2
IF in
NOM 2
Nominal IF input port # 2
45-95 MHz (-3 dB bandwidth)
-15 to -120 dBm, 50 
BNC Female
ALTERNATE IF
2
DL ALT IF2
IF in
ALT 2
Alternate IF input port # 2
45-95 MHz (-3 dB bandwidth)
-15 to -120 dBm, 50 
BNC Female
NOMINAL IF
3
DL NOM IF3
IF in
NOM 3
Nominal IF input port # 3
45-95 MHz (-3 dB bandwidth)
-15 to -120 dBm, 50 
BNC Female
ALTERNATE IF
3
DL ALT IF2
IF in
ALT 3
Alternate IF input port # 3
45-95 MHz (-3 dB bandwidth)
-15 to -120 dBm, 50 
BNC Female
AUXILIARY
1
DL AUX1
Note 1
Auxiliary input port # 1
DC to 90 MHz
0.1 to 0.5 Vpp (at BB)
0 to -20 dBm (at IF)
50 
BNC Female
AUXILIARY
2
DL AUX2
Note 1
Auxiliary input port # 2
DC to 90 MHz
0.1 to 0.5 Vpp (at BB)
0 to -20 dBm (at IF)
50 
