1 About this Manual
This manual describes the Sirius 800 router range, and the configuration of the various
modules that can be added to the range.
Refer to the individual Installation and Quick Start manuals for details on how to unpack,
install and test the Sirius 800 routers and the Sirius 800 Maintenance & Upgrade manual for
maintenance information.
Refer to the Workbench manual for details on configuring hardware and software panels.
If you have any questions regarding the installation and setup of your product, please refer to
the Customer Service contact details (see section 1.2).
1.1 Software and Firmware Release Details
This version of the Sirius 800 user manual documents the features and functions available
with Workbench version 3.17.x and firmware release PA1250x. These features are shown in
summary in Table 1
Firmware release notes are included with the firmware and are available on request from
SAM Customer Service, see section 1.2 for contact details.
1.1.1 Export System Information (Nucleus2 only)
Router system information can be exported to a CSV file by right clicking on the controller in
the configuration screen of Workbench. System information saved includes; hardware module
types, hardware versions, firmware versions, software versions, Workbench details and
database location information. See the Workbench manual for information on using
Workbench.
Firmware
Release
Version
Module AHP Features Supported
3.0.x
Nucleus2
2464/
2463
AHP control
(software/firmware supplied with the Workbench release).
PA1250x 4915 Gain, Phase Invert, Left/Right Swap, Left Both, Right Both, Mono Mix.
PA1250x 5919
Audio De-embedding, Gain, Phase Invert, 16 Channel Mix and Channel
Swap (Shuffle), Video Frame/Line Sync, Video Delay,
Audio Input Embedding.
PA1250x 4929
Gain, Phase Invert, Left/Right Swap, Left Both, Right Both, Mono Mix,
Audio Delay, Sample Rate Convert.
PA1250x 5949
16 Channel Mix, Channel Swap (Shuffle), Gain, Phase Invert and Audio
Embedding, Video Frame/Line Sync, Video Delay.
Crosspoint Modules:
PA1250x 5903 Audio crosspoint operation, Audio Input Embedding.
PA1250x 5905 Video crosspoint operation.
Modules no longer supplied with new systems:
PA1250x 5915
Audio De-embedding, Gain, Phase Invert, 16 Channel Mix and Channel
Swap (Shuffle).
PA1250x 4925 Gain, Phase Invert, Left/Right Swap, Left Both, Right Both, Mono Mix.
PA1250x 5925
16 Channel Mix, Channel Swap (Shuffle), Gain, Phase Invert and Audio
Embedding.
Table 1 Firmware Release History
