Sirius 800 Series User Manual Physical Specifications D.4
Iss 5 Rev 7 Page 364 © 2017 SAM
D.4 Physical
D.4.1 Sirius 830 Frame
D.4.2 Sirius 840 Frame
Sirius 830 Frame
Weight Between 73 kg (161 lbs) and 85 kg (187 lbs) typical full frame
(without packaging and depending on modules fitted)
Height 15RU chassis - 668 mm (26.3 inches)
Power requirements Auto ranging 100 Vac to 240 Vac, 50/60 Hz via external power
supply shelf/shelves (see Table 131). See Appendix B.1.1 on page
304 for details on the number of power supply shelves and power
supply units required.
Inrush Current up to 6.0 A
Max Rated Power 2500 W for video only routing on a fully equipped system.
6500 W for video and audio routing on a fully equipped system.
Power Consumption for Typical Usage Examples:
Fully Equipped - Standard Video modules all Coax.
No monitoring or redundancy options.
1750 W
Fully Equipped - Standard Video modules all Fiber.
No monitoring or redundancy options.
2000 W
Fully Equipped - 50% standard Video, 50% Video AHP,
all Coax. No monitoring or redundancy options.
2970 W
Additional - Redundant Video crosspoints 50 W
Additional - Redundant Audio crosspoints 55 W
Additional - 96 MV outputs 320 W
Table 127 Sirius 830 Frame Details
Sirius 840 Frame
Weight Between 150 kg (330 lbs) and 175 kg (386 lbs) typical full frame
(without packaging and depending on modules fitted)
Height 27RU chassis - 1198mm (47.17 inches)
Power requirements Auto ranging 100 Vac to 240 Vac, 50/60Hz via external power
supply shelf/shelves (see Table 131). See Appendix B.1.2 on
page 305 for details on the number of power supply shelves and
power supply units required.
Inrush Current up to 7.0 A
Max Rated Power 7000 W for video only routing on a fully equipped system.
13000 W for video and audio routing on a fully equipped system.
Power Consumption for Typical Usage Examples:
Fully Equipped - Standard Video modules all Coax.
No monitoring or redundancy options.
3250 W
Fully Equipped - Standard Video modules all Fiber.
No monitoring or redundancy options.
3800 W
Fully Equipped - 50% standard Video, 50% Video AHP,
all Coax. No monitoring or redundancy options.
5640 W
Additional - Redundant Video crosspoints 50 W
Additional - Redundant Audio crosspoints 55 W
Additional - 96 MV outputs 320 W
Table 128 Sirius 840 Frame Details
