Sirius 800 Series User Manual 5939 Sirius 830 Video & Audio, I/p & O/p Monitoring Multiviewer & Input/Output Monitoring Modules 13.7
Iss 5 Rev 7 Page 242 © 2017 SAM
13.7 5939 Sirius 830 Video & Audio, I/p & O/p Monitoring
5939 Sirius 830 Video & Audio, Input & Output Monitoring Module:
The 5939 Sirius 830 video & audio, input & output monitoring module is compatible with the
1237 rear panel (see section 13.9).
Note:
• The 5939 Input/Output module must be configured in Workbench before it can be
used. The 5939 module is configured from the Local Router Hardware tab,
Advanced Configuration, Edit Module Configurations... See the Workbench
user manual for module configuration details.
•The Modules Present screen of the Door PC can be used to check that the
Input/Output Monitoring module is correctly configured, see section 5.2.2.
Figure 170 5939 Sirius 830 Video & Audio, Input & Output Monitoring Module
LEDs
Connectors to
the Motherboard
