Sirius 800 Series User Manual Outputs Specifications D.2
Iss 5 Rev 7 Page 362 © 2017 SAM
D.2.5 Multiviewer and Additional Coax Outputs 577 to 1152 (No Longer Supplied)
5925
5931 External Multiviewer Output Module used with
1291 or 1309 MV DIN 1.0/2.3 Coax Output Rear Panels
5928 Standard Video Expansion Output Module (Sirius 850 Only) used with
1293 DIN 1.0/2.3 Coax Output Rear Panels for Additional Outputs 577 to 1152
Type Multiviewer (1291 & 1309): 48 per module, re-clocked
Additional Outputs (1293): 24 per module, re-clocked
Connectors DIN 1.0/2.3 Gold plated.
Standards Supported SMPTE-259M 525 and 625 SD-SDI
EN50083-9 DVB-ASI
SMPTE 292M 720p and 1080i HD-SDI
SMPTE 424M 1080p 3G-SDI
Impedance 75
Data Rate 3 Mb/s - 3 Gb/s. Standard video rates re-clocked, all other rates
auto-bypassed.
Return Loss >15dB 10MHz to 1.5GHz
>10dB 1.5GHz to 3GHz
Amplitude 800 mV pk-pk ±10% @ SD & HD
600 mV pk-pk ±10% @ 3G
Rise/Fall time <800ps @ SD
<440ps @ HD
<200ps @ 3G
Timing Jitter <0.15UI @ SD
<0.35UI @ 1.5G
<0.2UI @ 3G,
Alignment Jitter <0.15UI @ SD
<0.2UI @ 1.5G and 3G
DC Offset 0 V ± 0.5 V
Table 122 Multiviewer and Additional Coax Outputs (No Longer Supplied)
