Sirius 800 Series User Manual 2464/2463 Nucleus2 Router Control Module Nucleus Router Control Modules 14.4
Iss 5 Rev 7 Page 264 © 2017 SAM
14.4.5 Nucleus2: Sirius 800 Input and Output Port Mapping
14.4.5.1 Sirius 830: Input and Output Port Mapping
Table 68 shows the Sirius 830 crosspoint address mapping:
14.4.5.2 Sirius 840: Input and Output Port Mapping
Frame ID Switch set to 3 - see section 16.3.1.
Table 69 shows the Sirius 840 crosspoint address mapping:
• The information in this section is only correct if the Sirius 800 router is fitted with
Nucleus2 router controllers with the default database. Databases can be modified
including the mapping information.
• If the router is shipped with a custom database the mapping may vary but can be
checked and edited using the Workbench software, see the Workbench User
Manual for details.
Input/Output Range Addresses
Video Inputs 1 to 288 Source 0 to 287
Main Video Outputs 1 to 288 Destination 0 to 287
Multiviewer Outputs 1 to 140 Destination 1152 to 1291
Monitoring Outputs 1 to 4 Destination 16370 to 16373
Video Destinations 289 to 1152 are not used and do not respond to any control
Audio Inputs
(Nucleus2 only)
1 to 9216 Source 0 to 9215
Audio Outputs
(Nucleus2 only)
1 to 9216 Destination 0 to 9215
Table 68 Sirius 830 Input and Output Port Mapping
Input/Output Range Addresses
Video Inputs 1 to 576 Source 0 to 575
Main Video Outputs 1 to 576 Destination 0 to 575
Multiviewer Outputs 1 to 140 Destination 1152 to 1291
Monitoring Outputs 1 to 4 Destination 16370 to 16373
Video Destinations 577 to 1152 are not used and do not respond to any control
Audio Inputs
(Nucleus2 only)
1 to 18432 Source 0 to 18431
Audio Outputs
(Nucleus2 only)
1 to 18432 Destination 0 to 18431
Table 69 Sirius 840 Input and Output Port Mapping
