6.1 Signal Status
Catsii LED signal status is driven directly from the input and output modules, and changes
quickly when a Fiber, HD BNC or BNC cable is connected to the Sirius 800.
6.1.1 Video Signal Catsii Colors
Note:
Pulsed means 75% solid color, 25% pulsed color at ~ 1Hz.
Signal Condition - Video Input (5913/5914/5916/5917)
& Output (5923/5924/5926/5937/5938)
Default color
[1]
[1]
The current default Catsii colors are shown on the Door PC (see section 6.2.1) and
can be changed through Workbench (see section 6.3).
No valid signal Red
Valid SD signal Yellow
DVB-ASI Signal Yellow - pulsed off
Valid 1080i or 1080p (30 Hz or lower) signal Green
Valid 720p signal Green - pulsed off
Valid 3G signal Blue
Table 11 Default Video Catsii Configuration
Signal Condition - Video Input (5919/5915) & Output (5949/5925) Default color
[1]
[1]
The current default Catsii colors are shown on the Door PC (see section 6.2.1) and
can be changed through Workbench (see section 6.3).
No valid signal Red
Valid SD signal with no embedded audio Yellow
Valid SD signal with embedded audio Yellow - pulsed White
DVB-ASI Signal Yellow - pulsed off
Valid 1080i or 1080p (30 Hz or lower) signal with no embedded audio Green
Valid 1080i or 1080p (30 Hz or lower) signal with embedded audio Green - pulsed White
Valid 720p signal with no embedded audio Green - pulsed off
Valid 720p signal with embedded audio Green - pulsed White
Valid 3G signal with no embedded audio Blue
Valid 3G signal with embedded audio Blue - pulsed White
Table 12 Default Video with Embedded Audio Catsii Configuration
