D.1.2 Video AHP Inputs
5919 and 5915 - Video AHP Input Modules
Video Processing - 5919 only (optional Licensed features - see section 3.6)
Video Processing License, SAM Order Code: S8AHP-VF, 1 license, 8 assignable channels
(assigned to any input or output channels)
*Frame/Line Sync and Video Delay *Frame Sync offset: set in frames, lines and pixels or
milliseconds
*Line Sync offset: set in pixels or milliseconds
*Video Delay: set in pixels
*The video processing block can be used for frame/line sync or video delay on a channel by
channel basis but they cannot both be used on the same channel.
Input Standard 1125 (1080)/50P (A & B - Level B dual link only)
1125 (1080)/59P (A & B - Level B dual link only)
1125 (1080)/29i
1125 (1080)/25i
750 (720)/59P
750 (720)/50P
525 (480)/29i
625 (576)/25i
Default Video Output Standard Last known good
Controls (per channel) Genlock & Video Delay
Genlock Mode Lock to Reference, Lock to Input
Genlock H-Phase ±0.5H in pixel clock steps
Genlock V-Phase ±0.5F in 1 line steps
Video H-Delay 0 - 1 Line in pixel clock steps
Video V-Delay 0 - 1 Frame in 1 line steps
Video Delay 0 - 14 Pictures
(Picture = Frame in progressive formats)
(Picture = Field in interlaced formats)
Reference Select Mode Configured for each input or output - any of 4 looping
references or internally derived references
Other Controls
Action on
Loss of Input
Freeze, Black (configurable)
HANC Data Blank On/Off
On removes all HANC data.
Note: this includes removal of embedded audio
VANC Data Blank On = Blank all VANC interval
Off = Pass VANC except SMPTE defined switching
line and line following
Other Functions
DVB-ASI Handling Automatically detected and passed transparently
Synchronization Method Video and audio frame drop/repeat
Audio Selection Pre or post video synchronization
Freeze Field on interlaced standards
Frame in progressive standards
Minimum Delay (Reference lock or
free run)
2 µs to 7 µs for all formats (dependent on hysteresis
state)
Synchronizer Hysteresis Window 5 µs
Table 115 5919 and 5915 Video AHP Input Modules
