Sirius 800 Series User Manual Inputs Specifications D.1
Iss 5 Rev 7 Page 353 © 2017 SAM
Embedded Audio Delay - 5919 only (optional Licensed feature - see section 3.6)
Embedded Audio Delay License, SAM Order Code: S8AHP-VD (1 per module, 24 channels)
Audio Delay Per audio input channel in steps of 0.25 ms in a range
of 0 to 5.46 Seconds.
Embedded Audio Processing (including de-embedding)
- 5919 & 5915 (optional Licensed features - see section 3.6)
Embedded Audio Processing License, SAM Order Code: S8AHP-VA (1 per module,
24 channels)
Audio phase Invert Available per mono or stereo signal.
NORMAL/INVERT control (on/off)
Audio Gain/Mute adjustment Per mono or stereo signal.
Silence (Mute) or -72 to +30 dB in 0.1 dB steps
Audio mixing Up to 16 mono channels per mix.
Gain adjustment range per channel -Silence or -72 to
+30 dB in 0.1 dB steps
Channel Swap (shuffle) Change the channel order of up to 16 audio inputs.
Video Format Audio Channels Format
525/625 Up to 16 SMPTE ST259 carrier:
Embedded Audio to SMPTE ST272ADEF;
synchronous and asynchronous, 20 bit audio packets
only
720p Up to 16 SMPTE ST292 carrier:
SMPTE ST296 720p - 4:2:2 10 bit, 50/59.94/60
progressive frames/s.
Embedded Audio to SMPTE ST299-1
Audio synchronous or asynchronous to video
48 kHz nominal sample rate
1080i Up to 16 SMPTE ST292 carrier:
SMPTE ST274 1080i - 4:2:2 10 bit, 25/29.97/30
interlaced frames/s
Embedded Audio to SMPTE ST299-1
Audio synchronous or asynchronous to video
48 kHz nominal sample rate
1080p Up to 16 SMPTE ST424M carrier:
SMPTE ST 425M Level A - 1080p 4:2:2 10 bit
50/59.94/60 progressive frames/s (Mapping
structure 1)
Embedded Audio to SMPTE299-1 & ST299-2
Audio synchronous or asynchronous to video
48 kHz nominal sample rate
Up to 16 SMPTE ST 425 Level B Dual Link, mapped to SMPTE
ST372/ST274 - 4:2:2 10bit at 50/59.94/60 progressive
frames/s
Embedded Audio to SMPTE ST299
Audio synchronous or asynchronous to video
48 kHz nominal sample rate
5919 and 5915 - Video AHP Input Modules
Table 115 5919 and 5915 Video AHP Input Modules
