14.5 Nucleus 2450 Router Controller Card
Refer to the Workbench manual for details about configuring the Nucleus Controller.
14.5.1 Nucleus 2450 Controller LEDs
The LEDs on the Nucleus controller card are shown in Figure 182 and Table 73 lists the 2450
Nucleus controller LED functions. Table 73
Figure 181 Nucleus 2450 Control Module
Note:
• The Nucleus controller has a default database, use Workbench to configure the
modules in the Sirius 800. Modules are configured from the Local Router
hardware tab | Advanced Configuration | Edit Module Configurations... in
Workbench. See the Workbench manual for full details.
• The IP address of the Nucleus controller is found in the Config.ini file, see section
14.5.6.
LEDs, see
section
14.5.1
Compact Flash Card,
see section 14.5.3
Reset Switch
Jumpers - Factory
Use Only
Figure 182 Nucleus 2450 Controller LEDs
D4
D5
D6
D9
D10
D11
D12
D13
D14
D15
D16
