Sirius 800 Series User Manual I/O Port Connector Identification Catsii Functionality 6.2
Iss 5 Rev 7 Page 81 © 2017 SAM
6.1.2 MADI Audio Catsii Colors
6.2 I/O Port Connector Identification
For connector identification, when an input or output is selected from Workbench, the
following happens:
All LEDs turn off except:
• Yellow - The column of the selected connector
• Yellow - The row of the selected connector
• Flashing Red/Yellow - The selected connector
Signal Condition - MADI Input (4915) & Output (4929/4925) Default color
[1]
[1]
The current default Catsii colors are shown on the Door PC (see section 6.2.1) and
can be changed through Workbench (see section 6.3).
No valid MADI signal Red
56 Channel MADI @ 48 kHz Yellow - pulsed Off
56 Channel MADI @ 44.1 kHz Yellow - pulsed Blue
56 Channel MADI @ other sample rates Yellow - pulsed Red
Valid 56 Channel MADI Redundant signal (input only) Yellow
64 Channel MADI @ 48 kHz Green - pulsed Off
64 Channel MADI @ 44.1 kHz Green - pulsed Blue
64 Channel MADI @ other sample rates Green - pulsed Red
Valid 64 Channel MADI Redundant signal (input only) Green
Table 13 Default Audio Catsii Configurations
