11.1.1 Duplicate MADI Outputs
When fitted with the 1295 or 1296 MADI rear panels the 4929 module outputs 12 MADI
channels and a further 12 duplicate MADI channels.
The main and backup connections are shown in the rear panel diagrams listed below:
11.1.2 Configuring MADI to 56 or 64 Channels
Individual MADI channels are configured to output in 56 or 64 channel MADI using the
Workbench Online Editor.
Nucleus2 Router Control Module Navigate to:
Controller | Devices | Devices[1]: LocalRouterDevice |
LocalRouterConfig | ModuleConfigurations |
ModuleConfiguration[XXX]: AudioOutput | MADIControl |
MADIControl[YY] | Format=
Where:
XXX= the Module ID of the Audio Output Module (see the Workbench manual for details)
YY = the MADI channel (1 to 12) being configured
Select the number of MADI channels from the drop down menu:
• MADI56 = configures the MADI channel to 56 channels
• MADI64 = configures the MADI channel to 64 channels
Rear Panel See Figure Number
1295 BNC rear panel See Figure 130 on page 200.
1296 Fiber rear panel See Figure 131 on page 201.
Table 39 MADI Main and Backup Connections
Ensure both Nucleus2 router control modules are configured the same by using the Copy
to Partner function in Workbench once configurations changes have been made.
