Sirius 800 Series User Manual 4915 Sirius 800 AES/MADI Input Module Input Rear Panels and Input Modules 9.17
Iss 5 Rev 7 Page 133 © 2017 SAM
9.17 4915 Sirius 800 AES/MADI Input Module
The 4915 AES/MADI input module can accept either 120 AES inputs (balanced or
unbalanced) with up to 3 MADI input channels or 12 channels of MADI inputs depending on
the rear panel fitted. The 4915 Input Module is compatible with the rear panels listed in
Table 22
Important:
Early Sirius 800 routers must be modified by SAM before they can be used with the 4915.
see section 3.13 to check if the router needs modifying.
Rear Panel See Section
Up to 120 AES inputs and up to 3 MADI input channels:
Sirius 830:
1354 Balanced AES + HD BNC MADI rear panel see section 9.14.1
1357 Unbalanced AES + HD BNC MADI rear panel see section 9.15.1
1299 Balanced AES rear panel (no MADI) - No longer supplied See Appendix C.1.1
Sirius 840/850:
1352 Balanced AES + HD BNC MADI rear panel see section 9.14.2
1355 Unbalanced AES + HD BNC MADI rear panel see section 9.15.2
1297 Balanced AES rear panel (no MADI) - No longer supplied See Appendix C.1.2
Up to 12 MADI input channels:
Sirius 830:
1303 MADI Input BNC rear panel see section 9.5
1304 MADI Input Fiber rear panel see section 9.6
Sirius 840/850:
1285 MADI Input BNC rear panel see section 9.7
1286 MADI Input Fiber rear panel see section 9.8
Table 22 4915 Rear Panel Compatibility
