Sirius 800 Series User Manual 5901 Sirius 800 Series Video Crosspoint Modules No Longer Supplied With New Systems C.3
Iss 5 Rev 7 Page 323 © 2017 SAM
C.3.1 Video Crosspoint Module LED Information
Table 100 shows the LED color code on the Video Crosspoint Modules, and Figure 206
shows the front edge of the module.
Figure 206 5901 Video Crosspoint Module LEDs
If the active LED is not illuminated, it is safe to remove the video crosspoint module without
affecting any active routes.
LED Color Label Detail Status
Green Power OK Power to the module On Solid - working correctly
Green
PAL OK FPGA Working Flashing - the FPGA is working
correctly
Yellow
Command
OK
Command from the Control
module
Flashing - receiving information and
working correctly
Red
Command
Error
Error with command from
the Control module
Off - normal state
Flashing - the command message
from the router controller is corrupt or
hasn’t been received. If all of the
crosspoint modules indicate a
Command Error check that the router
controller is operating correctly. If only
one of the crosspoint modules
indicates the error contact SAM
Customer Support (see section 1.2 for
contact details).
Yellow
Switch Flashes on a take signal
when switching a route
Off - normal state
Flashes - each time a route is set
Red
Xpt Error Displays if there is a
problem with any
crosspoints
Off - normal state
On solid - problem with one or more
crosspoints on the module.
Flashing - Crosspoint module
overheating, make sure the fan
assemblies are all closed and the fans
are all operating correctly.
Yellow
Active Route is active on
crosspoint
Flashing - when this module is routing
one or more signals to live outputs.
Removing the crosspoint module will
disturb the signal(s) passing through
the crosspoint module.
Red
Route Fail Illuminated if a route failure
has been detected on this
crosspoint
Off - normal state
Flashing - receiving error messages
related to a route failure
Table 100 5901 Video Crosspoint Module LED Information
Power OK
Command OK
Command Error
Switch
PAL OK
Xpt Error
Active
Route Fail
5901
