Sirius 800 Series User Manual Control/Fan Interface Module

15 Control/Fan Interface Module

Two Control/fan interface modules are fitted in each router. The control/fan interface modules

performs the following functions:

• Fanning out of the control busses

• Dual redundant fan out of control busses

• Driving all the fans

• Dual redundant fan power

• Collecting alarm signals from power supply shelves and fans.

• Generating relay alarm outputs

In addition to the above functions, the module has the following secondary functions:

• Providing power to the LED's in the door

• Providing power and control to the Catsii LED's on the control rear panel

Figure 187 Control/Fan Interface Module - Video Processing Compatible Version Shown

LEDs

Connectors to

the Motherboard

Connectors to

the Bottom

Motherboard
