Sirius 800 Series User Manual Inputs Specifications D.1
Iss 5 Rev 7 Page 351 © 2017 SAM
Appendix D Specifications
D.1 Inputs
D.1.1 Video Inputs
5917, 5919, 5913, 5915 and 5916 Video Input Modules used with
1234, 1349, 1235, 1285 or 1289 Main Coax Video Input Rear Panels
or 1360, 1372 Main HD BNC Video Input Rear Panels
or 1362 DS-Link Video Input Rear Panels
Number and type 24 per module automatic cable equalisation and re-clocked
Connectors BNC, 75 electrical impedance. Gold plated.
HD BNC, 75 electrical impedance. Gold plated.
DS-Link, Densishield highspeed cable connector
(proprietary connector format)
Standards supported SMPTE-259M 525 and 625 SD-SDI
EN50083-9 DVB-ASI
SMPTE 292M 720p and 1080i HD-SDI
SMPTE 424M 1080p 3G-SDI
Impedance 75
Data rate 3 Mb/s - 3 Gb/s. Standard video rates re-clocked, all other rates
auto-bypassed.
Return loss >15dB 10MHz to 1.5GHz
>10dB 1.5GHz to 3GHz
Amplitude 800mV p-p nominal
DC offset <5V
Cable Equalisation Automatic for:
Up to 350 m (1150 feet) Belden 1694A, PSF1/2M at SD rates
Up to 200 m (650 feet) Belden 1694A at HD
Up to 140 m (460 feet) Belden 1694A at 3G
Table 113 Main Video Inputs
5917, 5919, 5914, 5915 and 5916 Video Input Modules used with
1236, 1286, 1361, 1373 or 1305 Main Optical Input Rear Panels
Number and type 24 per module, re-clocked - removable video SFP modules
Note: Specifications are based on fitting standard SFP receivers - SAM Order Code SRR-3
Connectors LC/PC single mode fiber connection as standard.
Wavelength Wideband receiver, 1260-1620 nm nominal
Sensitivity -18 dBm
Typical link length 10km @ 3 Gb/s
20km @ 1.5 Gb/s
30km @ 270MBit/s
Standards supported SMPTE-259M 525 and 625 SD-SDI
EN50083-9 DVB-ASI
SMPTE 292M 720p and 1080i HD-SDI
SMPTE 424M 1080p 3G-SDI
Table 114 Main Optical Video Inputs
