C.4.2 5923/4 Sirius 840/850 Standard Video Output Module
The 5923 Sirius 840/850 standard video BNC output module connects to the 1295 rear panel
(see section 11.8) which has 24 BNC outputs.
The 5924 Sirius 840/850 standard video BNC output module connects to the 1296 rear panel
(see section 11.9) which has 24 Fiber outputs which are split into 12 dual channel
transmitters.
• The 5923 and 5924 video output modules were supplied with earlier Sirius 840/850
router systems and are shown here for users that already have them fitted.
Possible alternative output modules and rear panels:
• On Sirius 840 routers:
A 5926 standard video output module and its accompanying rear panel can be
used instead of either the 5923 or 5924 and their rear panels.
The Module / Rear panel pair (5923 / 1295 or 5924 / 1296) must be changed.
See Table 104 below for module/rear alternatives.
• On Sirius 840 and 850 routers:
A 5938 expandable video output module and its accompanying rear panel can be
used instead of either the 5923 or 5924 and their rear panels.
The Module / Rear panel pair (5923 / 1295 or 5924 / 1296) must be changed.
See Table 104 below for module/rear alternatives.
Module/Rear Substitute Module / Rear pairs
Sirius 840 Sirius 850
5923 / 1295
or
5924 / 1296
5938 / 1294(BNC)
or 5938 / 1363(HD-BNC)
or 5938 / 1302(Fiber)
or 5938 / 1364(DS-Link)
or 5926 / 1294(BNC)
or 5926 / 1363(HD-BNC)
or 5926 / 1302(Fiber)
or 5926 / 1364(DS-Link)
5938 / 1294(BNC)
or 5938 / 1363(HD-BNC)
or 5938 / 1302(Fiber)
or 5938 / 1364(DS-Link)
Table 104 Alternative Module/Rear pairs
More information on the alternative modules and rears:
• For more information on the 5926, see Section 11.2 “5926 Sirius 800
Standard Video Output (Non Expandable)” on page 185.
• For more information on the 5938, see Section 12.3 “5938 Sirius 850
Standard Video O/p (Expandable)” on page 216.
