The 5923 video output module is compatible with the 1295 BNC rear panel (see section 11.8).
The 5924 output module is compatible with the 1296 Fiber rear panel (see section 11.9).
Figure 211 5923/5924 Sirius 840/850 Standard Video Output Module
LEDs
Connectors to
the Motherboard
Connectors to the
1295
or
1296 Rear
Module
