Sam Sirius 830 - Sirius 850 Monitoring and Multiviewer; Sirius 850: Multiviewer Outputs Only (no Monitoring)

Sirius 800 Series User Manual Sirius 850 Monitoring and Multiviewer Multiviewer & Input/Output Monitoring Modules 13.4
Iss 5 Rev 7 Page 234 © 2017 SAM
13.4 Sirius 850 Monitoring and Multiviewer
13.4.1 Sirius 850: Multiviewer Outputs Only (no monitoring)
• 5902 (qty 1) Multiviewer Crosspoint module
• 5931 (qty 1 to 2) External Multiviewer Output module(s)
• 1370 (qty 1 to 2) External Multiviewer HD BNC Rear panel(s)
• MV-800 (qty 1-2) Integrated Multiviewer
• MV-800-RP (qty 1-2) MV-800 Rear Panel
Figure 161Multiviewer Outputs Only (No Monitoring) Option (Sirius 850)
1 x 5902 Multiviewer Crosspoint
Module, see section 13.7
Video/Audio
Inputs
MV
73 to 120
Up to two 5931 External Multiviewer Output Modules,
see section 13.6.1
Up to two MV-800 Integrated Multiviewer Modules
Up to two 1370 Ext. Multiviewer HD BNC Rear Panels,
see section 13.11
Up to two MV-800-RP MV-800 Rear Panels
MV
1 to 48
5931 /
MV-800
5931 /
MV-800
Note:
• Earlier Sirius 850 systems were sometimes fitted with 5932 multiviewer output
module(s) and either 1291 multiviewer coax rear panel(s) or 1292 MV-Link rear
panel(s).
• The 1292 MV-Link rear enabled up to 140 multiviewer outputs to be connected to a
Miranda KaleidoX multiviewer, see sections C.6.3 and C.6.4 for details.
• 5932 modules and 1292 rear panels are no longer available and are shown here
for users that already have them fitted.
