Sam Sirius 830 User Manual

Sirius 800 Series User Manual Sirius 850 Frame Dimensions Router and Power Supply Shelf Dimensions A.3
Iss 5 Rev 7 Page 302 © 2017 SAM
A.3 Sirius 850 Frame Dimensions
Make sure that sufficient space is available for the Sirius 850. For ventilation purposes, there
must be an additional 50 mm (2 inch) gap on the left and right sides.
The full height of the Sirius 850 is 1511 mm (59.49 inches). Allow an additional 200 mm
(8 inches) behind the unit for power, control and signal cables.
Figure 194 Sirius 850 Frame Dimensions
Dimensions are of full size system (without the
power supplies)
Dimensions are in millimeters (inches).

Sam Sirius 830 Specifications

General

Category	Network Router
Maximum Speed	1200 Mbps
Wireless Standards	IEEE 802.11ac
Frequency Band	2.4 GHz / 5 GHz
Ports	4 x Gigabit Ethernet
Security	WPA/WPA2
