Sirius 800 Series User Manual Configuring Video/Audio Crosspoint Failure Action Crosspoint Modules 10.7
Iss 5 Rev 7 Page 173 © 2017 SAM
10.7 Configuring Video/Audio Crosspoint Failure Action
The action on crosspoint failure for video and audio is set from the Workbench controller
online editor. See the Workbench manual for information on using the online editor.
Nucleus2 Controller Navigate to:
Devices | Devices[1]: LocalRouterDevice | LocalRouterControl |
RouterSpecificControl: Sirius800Control
Nucleus (2450) Controller Navigate to:
Control2450| CommonControl|RouterSpecificControl: Sirius800Control |
Nucleus2 & Nucleus (2450) Controllers
Video navigate to:
| RedundantXpntControl | ActionOnFail = MoveFailedRoute|
Select the required action from the drop down menu:
• NoAction = Notify the user and leave them to take appropriate action
• MoveFailedRoute = Move the failed route to the redundant crosspoint (default when
shipped)
• MoveAllRoutes = Move all routes from the crosspoint with the failure to the redundant
crosspoint
Audio (Nucleus2 only) navigate to:
| RedundantAudioXpntControl | FailedAction = MoveFailedStream|
Select the required action from the drop down menu:
• MoveFailedStream = Move the failed stream to the redundant crosspoint (default
when shipped)
• MoveAllStreams = Move all streams from the crosspoint with the failure to the
redundant crosspoint
• If the video or audio action on fail setting is changed the controller must be reset for
the new settings to take effect.
• If video or audio redundancy is enabled or disabled (see section 10.6) make these
changes at the same time and push the configuration to the controller using
Workbench, a reset is not be required after the push.
• In a dual controller system both controllers must have the same redundancy
settings.
