14.4.5.3 Sirius 850: Input and Output Port Mapping
Sirius 850 Single Frame: Frame 1 of 1 (Frame ID Switch set to 0 - see section 16.3.1)
Table 70 shows the Sirius 850 crosspoint address mapping for Frame 1 of 1:
Sirius 850 Dual Frames: Frame 1 of 2 (Frame ID Switch set to 1 - see section 16.3.1)
Table 71 shows the Sirius 850 crosspoint address mapping for Frame 1 of 2:
Input/Output Range Addresses
Video Inputs 1 to 576 Source 0 to 575
Main Video Outputs 1 to 576 Destination 0 to 575
Expansion Video Outputs
(using 5928 expansion modules &
1366 expansion output
rear panels)
577 to 1152 576 to 1151
*Multiviewer Outputs
(using two 1291 multiviewer
rear panels)
1 to 96
Destination 1152 to 1199
&
Destination 1224 to 1271
*Multiviewer Outputs: 1152 to 1291 only if two 1292 multiviewer MV-Link rear panels are fitted
- (no longer supplied)
Monitoring Outputs 1 to 4 Destination 16370 to 16373
Audio Inputs
(Nucleus2 only)
1 to 18432 Source 0 to 18431
Audio Outputs
(Nucleus2 only)
1 to 18432 Destination 0 to 18431
Table 70 Sirius 850 Input and Output Port Mapping (Frame 1 of 1)
Input/Output Range Addresses
Video Inputs 1 to 1152 Source 0 to 1151
Main Video Outputs
(using 5928 expansion modules &
1365/1290 expansion output
rear panels)
1 to 576 Destination 0 to 575
*Multiviewer Outputs
(using two 1291 multiviewer
rear panels)
1 to 96
Destination 1152 to 1199
&
Destination 1224 to 1271
Destinations 577 to 1152 are not used and do not respond to any control
*Multiviewer Outputs: 1152 to 1291 only if two 1292 multiviewer MV-Link rear panels are fitted
- (no longer supplied)
Monitoring Outputs 1 to 4 Destination 16370 to 16373
Audio Inputs
(Nucleus2 only)
1 to 18432 Source 0 to 18431
Audio Outputs
(Nucleus2 only)
1 to 18432 Destination 0 to 18431
Table 71 Sirius 850 Input and Output Port Mapping (Frame 1 of 2)
