Sirius 800 Series User Manual Sirius 840/850 Module Locations 8.3
Iss 5 Rev 7 Page 103 © 2017 SAM
8.3.7.3 Input, Output and Expansion Connections by Slot
Input/Output Rear
Panel Slot
Number
Input/Output Channels
Video Channels
Embedded Audio
Channels
Sirius 850 only, Video
Expansion Inputs
(a, b, c)
Rear Panel Slot 1 1 to 24 1 to 768 577 to 600
Rear Panel Slot 2 25 to 48 769 to 1536 601 to 624
Rear Panel Slot 3 49 to 72 1537 to 2304 625 to 648
Rear Panel Slot 4 73 to 96 2305 to 3072 649 to 672
Rear Panel Slot 5 97 to 120 3073 to 3840 673 to 696
Rear Panel Slot 6 121 to 144 3841 to 4608 697 to 720
Rear Panel Slot 7 145 to 168 4609 to 5376 721 to 744
Rear Panel Slot 8 169 to 192 5377 to 6144 745 to 768
Rear Panel Slot 9 193 to 216 6145 to 6912 769 to 792
Rear Panel Slot 10 217 to 240 6913 to 7680 793 to 816
Rear Panel Slot 11 241 to 264 7681 to 8448 817 to 840
Rear Panel Slot 12 265 to 288 8449 to 9216 841 to 864
Rear Panel Slot 13 289 to 312 9217 to 9984 865 to 888
Rear Panel Slot 14 313 to 336 9985 to 10752 889 to 912
Rear Panel Slot 15 337 to 360 10753 to 11520 913 to 936
Rear Panel Slot 16 361 to 384 11521 to 12288 937 to 960
Rear Panel Slot 17 385 to 408 12289 to 13056 961 to 984
Rear Panel Slot 18 409 to 432 13057 to 13824 985 to 1008
Rear Panel Slot 19 433 to 456 13825 to 14592 1009 to 1032
Rear Panel Slot 20 457 to 480 14593 to 15360 1033 to 1056
Rear Panel Slot 21 481 to 504 15361 to 16128 1057 to 1080
Rear Panel Slot 22 505 to 528 16129 to 16896 1081 to 1104
Rear Panel Slot 23 529 to 552 16897 to 17664 1105 to 1128
Rear Panel Slot 24 553 to 576 17665 to 18432 1129 to 1152
Table 18 Sirius 840/850: Connector Channels by Rear Panel Slot
