Sirius 800 Series User Manual Balanced AES Input Rear Panels with MADI Inputs Input Rear Panels and Input Modules 9.14
Iss 5 Rev 7 Page 125 © 2017 SAM
Pin
Number
Socket 1 AES
Balanced
Input
Socket 2 AES
Balanced
Input
Socket 3 AES
Balanced
Input
Socket 4 AES
Balanced
Input
Socket 5 AES
Balanced
Input
24 1+ 25+ 49+ 73+ 97+
25 1- 25- 49- 73- 97-
22 2+ 26+ 50+ 74+ 98+
23 2- 26- 50- 74- 98-
1 3+ 27+ 51+ 75+ 99+
43 3- 27- 51- 75- 99-
2 4+ 28+ 52+ 76+ 100+
44 4- 28- 52- 76- 100-
3 5+ 29+ 53+ 77+ 101+
45 5- 29- 53- 77- 101-
4 6+ 30+ 54+ 78+ 102+
46 6- 30- 54- 78- 102-
5 7+ 31+ 55+ 79+ 103+
47 7- 31- 55- 79- 103-
6 8+ 32+ 56+ 80+ 104+
48 8- 32- 56- 80- 104-
7 9+ 33+ 57+ 81+ 105+
49 9- 33- 57- 81- 105-
8 10+ 34+ 58+ 82+ 106+
50 10- 34- 58- 82- 106-
9 11+ 35+ 59+ 83+ 107+
51 11- 35- 59- 83- 107-
10 12+ 36+ 60+ 84+ 108+
52 12- 36- 60- 84- 108-
11 13+ 37+ 61+ 85+ 109+
53 13- 37- 61- 85- 109-
12 14+ 38+ 62+ 86+ 110+
54 14- 38- 62- 86- 110-
13 15+ 39+ 63+ 87+ 111+
55 15- 39- 63- 87- 111-
14 16+ 40+ 64+ 88+ 112+
56 16- 40- 64- 88- 112-
15 17+ 41+ 65+ 89+ 113+
57 17- 41- 65- 89- 113-
16 18+ 42+ 66+ 90+ 114+
58 18- 42- 66- 90- 114-
17 19+ 43+ 67+ 91+ 115+
Table 19 Balanced AES Rear Panel 62 Way High Density AES Socket Pin Outs
