Sirius 800 Series User Manual Unbalanced AES Input Rear Panels with MADI Inputs Input Rear Panels and Input Modules 9.15
Iss 5 Rev 7 Page 130 © 2017 SAM
Pin
Number
Socket 1 AES
Unbalanced
Input
Socket 2 AES
Unbalanced
Input
Socket 3 AES
Unbalanced
Input
Socket 4 AES
Unbalanced
Input
Socket 5 AES
Unbalanced
Input
24 1+ 25+ 49+ 73+ 97+
25 GND GND GND GND GND
22 2+ 26+ 50+ 74+ 98+
23 GND GND GND GND GND
1 3+ 27+ 51+ 75+ 99+
43 GND GND GND GND GND
2 4+ 28+ 52+ 76+ 100+
44 GND GND GND GND GND
3 5+ 29+ 53+ 77+ 101+
45 GND GND GND GND GND
4 6+ 30+ 54+ 78+ 102+
46 GND GND GND GND GND
5 7+ 31+ 55+ 79+ 103+
47 GND GND GND GND GND
6 8+ 32+ 56+ 80+ 104+
48 GND GND GND GND GND
7 9+ 33+ 57+ 81+ 105+
49 GND GND GND GND GND
8 10+ 34+ 58+ 82+ 106+
50 GND GND GND GND GND
9 11+ 35+ 59+ 83+ 107+
51 GND GND GND GND GND
10 12+ 36+ 60+ 84+ 108+
52 GND GND GND GND GND
11 13+ 37+ 61+ 85+ 109+
53 GND GND GND GND GND
12 14+ 38+ 62+ 86+ 110+
54 GND GND GND GND GND
13 15+ 39+ 63+ 87+ 111+
55 GND GND GND GND GND
14 16+ 40+ 64+ 88+ 112+
56 GND GND GND GND GND
15 17+ 41+ 65+ 89+ 113+
57 GND GND GND GND GND
16 18+ 42+ 66+ 90+ 114+
58 GND GND GND GND GND
17 19+ 43+ 67+ 91+ 115+
Table 20 Unbalanced AES Rear Panel 62 Way High Density AES Socket Pin Outs
