Sirius 800 Series User Manual 5919 Sirius 800 Video AHP Input Module with Delay and Sync Input Rear Panels and Input

Figure 107 5919 Input Module LEDs

Power OK

Local Command OK

Local Error

Remote Command OK

Remote Error

Fugue Status

Diagnostic LEDs x 8

SAM use only

Top LED

Bottom LED
