Sirius 800 Series User Manual 1353 Balanced AES Output Rear with MADI Outputs Output Modules and Rear Panels 11.10
Iss 5 Rev 7 Page 205 © 2017 SAM
59 19- 43- 67- 91- 115-
18 20+ 44+ 68+ 92+ 116+
60 20- 44- 68- 92- 116-
19 21+ 45+ 69+ 93+ 117+
61 21- 45- 69- 93- 117-
20 22+ 46+ 70+ 94+ 118+
62 22- 46- 70- 94- 118-
41 23+ 47+ 71+ 95+ 119+
42 23- 47- 71- 95- 119-
39 24+ 48+ 72+ 96+ 120+
40 24- 48- 72- 96- 120-
21 N/CN/CN/CN/CN/C
26 to 38 Signal GND Signal GND Signal GND Signal GND Signal GND
Pin
Number
Socket 1 AES
Balanced
Output
Socket 2 AES
Balanced
Output
Socket 3 AES
Balanced
Output
Socket 4 AES
Balanced
Output
Socket 5 AES
Balanced
Output
Table 48 Balanced AES Rear Panel 62 Way High Density AES Connector Pin Outs (Continued)
