Serial Link Between Controllers
Displays the status of the serial link between the active and idle controllers. See
LED 5 for further information.
• Blue pulsing Green = Link okay, data is being transferred.
• Green pulsing Blue = Link okay, no data is being transferred.
• Magenta pulsing Blue = Link error, no connection with the other controller.
Indicates; the other controller is not present/not running or the serial link is
not working.
• Orange Pulses = Error, received data for unconfigured device
Indicates; the other controller is configured differently from the controller
receiving the data or it has no configuration.
• Red Pulses = Error, received data with invalid format.
Check both controllers are running the same version of CentraController.rtb
software. Workbench can be used to check the controller software versions
loaded.
5
Serial Data Replication (Local Router Device)
The Serial Link is used to replicate LocalRouter device data between the active and
idle controllers. Replicated data includes; crosspoint status, module configuration
and port configuration.
• Off = Active Controller
• Flashing Green = Idle controller, receiving background update data.
• Flashing Orange = Idle controller, data synchronisation with Active
controller in progress.
Note: Do not fail-over to the idle controller until data synchronization is
complete and the LED is flashing green on the idle controller as there is a
risk that data will become corrupted and affect the operation of the router.
6 Not used
7 Not used
LED Description
Table 66 Nucleus2 Router Control Module LEDs
