Sirius 800 Series User Manual Output Modules Modules No Longer Supplied With New Systems C.4

Figure 212 5923/5924 Sirius 840/850 Standard Video Output Module LEDs

Power OK

Command OK

Command Error

Remote Command OK

Remote Error

5923/5924
