Sirius 800 Series User Manual Output Modules Modules No Longer Supplied With New Systems C.4

Figure 215 5925 Sirius 800 Video AHP Output Module LEDs

Remote Command OK

Remote Error

Power OK

Local Command OK

Local Error

Fugue Status

Diagnostic LEDs x 8

Top LED

Bottom LED
