Embedded Audio Processing (including embedding)
- 5949 & 5925 (optional Licensed features - see section 3.6)
Embedded Audio Processing License, SAM Order Code: S8AHP-VA (1 per module,
24 channels)
Audio Mixing Up to 16 mono channels per mix. Selectable from
incoming video or separately routed audio.
Gain adjustment range per channel - Silence or
-72 to +30 dB in 0.1 dB steps
Channel Swap (Shuffle) Change the channel order of up to 16 audio outputs.
Audio phase Invert Available per mono or stereo signal.
NORMAL/INVERT control (on/off)
Audio Gain adjustment Per mono or stereo signal.
Silence or -72 to +30 dB in 0.1 dB steps
Audio Embedding Embedding onto each video signal is done
synchronously to the video signal.
All video signals operate independently to each
other.
Ancillary Data All VANC data is removed
All non-audio HANC (Horizontal Ancillary) data is
removed
Embedded Audio Delay - 5949 only (optional Licensed feature - see section 3.6)
Embedded Audio Delay License, SAM Order Code: S8AHP-VD (1 per module, 24 channels)
Audio Delay Per audio input channel in steps of 0.25 ms in a
range of 0 to 5.46 Seconds.
Video Format Audio Channels Format
525/625 Up to 16 SMPTE ST259 carrier:
Audio to SMPTE ST272 - level A (20 bits)
Synchronous to video at 48 kHz sample rate
nominal,
4 audio groups maximum for 525/59.94 or 525/60
720p Up to 16 SMPTE ST292M carrier:
SMPTE ST296M 720p - 4:2:2 10 bit, 50/59.94/60
progressive frames/s.
Embedded Audio to SMPTE ST299M
Synchronous to video at 48 kHz sample rate
nominal
1080i Up to 16 SMPTE ST292 carrier:
SMPTE ST274 1080i - 4:2:2 10 bit, 25/29.97/30
interlaced frames/s
Embedded Audio to SMPTE ST299
Synchronous to video at 48 kHz sample rate
nominal
5949 and 5925 - Video AHP Output Modules
Table 119 5949 and 5925 Video AHP Output Modules
