Sirius 830 Crosspoint Card Status Buttons
XpntCardRedundant830
button
Touch the button to bypass the redundant crosspoint card.
Grey = Redundant crosspoint card is working correctly.
Yellow = Redundant crosspoint card has failed or been
bypassed.
XpntCardMain830 button Touch the button to bypass the main crosspoint card.
Grey = Main crosspoint card is working correctly.
Yellow = Main crosspoint card has failed or been bypassed.
Sirius 840/850 Crosspoint Card Status Buttons
XpntCardOddToOdd_1
button
Touch the button to bypass crosspoint card 1.
Grey = Crosspoint card 1 is working correctly.
Yellow = Crosspoint card 1 has failed or been bypassed.
XpntCardEvenToOdd_2
button
Touch the button to bypass crosspoint card 2.
Grey = Crosspoint card 2 is working correctly.
Yellow = Crosspoint card 2 has failed or been bypassed.
XpntCardRedundant_R
button
Touch the button to bypass the redundant crosspoint card.
Grey = Redundant crosspoint card is working correctly.
Yellow = Redundant crosspoint card has failed or been
bypassed.
XpntCardOddToEven_3
button
Touch the button to bypass crosspoint card 3.
Grey = Crosspoint card 3 is working correctly.
Yellow = Crosspoint card 3 has failed or been bypassed.
XpntCardEvenToEven_4
button
Touch the button to bypass crosspoint card 4.
Grey = Crosspoint card 4 is working correctly.
Yellow = Crosspoint card 4 has failed or been bypassed.
Screen Item Description
Table 9 Video Crosspoint Matrix Status Screen
