Clock Master Displays the Audio Crosspoint module that is supplying the audio
system clock (Left or Right).
The Audio Crosspoint module either generates the audio system
clock (Clock Master) or uses the clock generated on the other
crosspoint (if fitted).
In normal operation the main crosspoint module generates the
audio system clock and the redundant crosspoint module is
slaved to that.
Failed Action Displays the action that will be carried out by the router when a
crosspoint fails. This is configured in Workbench, see section
10.7 for configuration details.
Configuration options available are:
• Move the failed stream to the redundant crosspoint
(default when shipped).
• Move all streams from the crosspoint module with the
failure to the redundant crosspoint module
First Failure Detected
(shown for Left and Right Audio Crosspoint Modules)
Failed Incoming Stream Displays the first incoming and first outgoing streams to fail on
each Audio Crosspoint module.
If all display zero and the Fail Found status is red then an entire
crosspoint module has failed. Check the Crosspoint Status of
crosspoint modules to determine which card has failed.
If both display zero and the Fail Found and Fail Present LEDs are
green then no fault has been found.
Failed Outgoing Stream
Totals
(shown for Left and Right Audio Crosspoint Modules)
Input Syncs OK Displays the total number of successful input syncs for the audio
crosspoint module.
Input Sync Faults Displays the total number of failed input syncs for the audio
crosspoint module.
0 = No input sync faults (good)
Input Syncs in Use Displays the total number of input syncs in use on the audio
crosspoint module.
Input Stream OK Displays the total number of input streams without faults on the
audio crosspoint module.
Input Stream Faults Displays the total number of input stream faults for the audio
crosspoint module.
0 = No failed input streams (good)
Output Stream OK Displays the total number of output streams without faults on the
audio crosspoint module.
Output Stream Fault Displays the total number of output stream faults for the audio
crosspoint module.
0 = No failed output streams (good)
Output Stream in Use Displays the total number of output streams in use on the audio
crosspoint module.
Screen Item Description
Table 10 Sirius 800 Audio Crosspoint Matrix Status and Crosspoint Switching
