WATER PUMP ASSEMBLY
3-7-3
No. Fastener
Torque
Remarks
N·m kgf·m ft·lb
1 Water pump cover
2 Bolt M6×30 9.8 1.0 87 in•lb
3 Bolt M6×95 9.8 1.0 87 in•lb
4 Bolt M6×12 9.8 1.0 87 in•lb
5 Aluminum washer 6
6 Steel belt elastic hose clamp 30
7 Small circulating water pipe
8 Water pump cover sealing ring
9 Bolt M6×16 9.8 1.0 87 in•lb
10 Disc spring 12.5×6.4×1
11 Combination washer
12 Water pump impeller
13 Oil seal 15×30×5
14 Bushing
15 Oil seal 15×28×5
16 OO-ring seal 8×2
17 Flat washer 13.1×25×1
18 Water pump shaft
G: Use grease suitable for oil seals and O-rings
L: Use fastening agent
.
O: Apply oil
.
SS: Use silicone sealant
.
S: Tighten in order
.
R: Spare parts
