14 - 34
ELECTRICAL SYSTEM
A
◆
After turn on the power lock, if the dashboard
does not display, please confi rm whether the
fuse is damaged；
◆
The fuse box is under the dashboard, first
open the electrical repair cover 【A】
◆
Press the fuse box cover lock 【B】 and
remove the fuse box cover
◆
Use a multimeter to test whether the fuse is
on
Fuse continuity test
◆
Before testing, disconnect the battery power
supply
◆
Place the multimeter in the on position
◆
Put the red and black test leads of the
multimeter to the two ends of the fuse
respectively
◆
If it can be turned on, it means that the fuse is
normal, and if it can’t be turned on, it means
that the fuse is damaged
B
Place the red and black test leads
of the multimeter at both ends
Before testing the fuse, disconnect the battery power
supply.
