Segway VILLIAN SSV Series User Manual

4 - 20
FRONT AXLE AND REAR GEARBOX
FRONT AXLE AND REAR GEARBOX
!
!
CAUTION
After installation, check that the parking arm
【
D
】
can be
fl exibly moved without jamming and rebounding.
Installation
【
A
】
Right gearbox
【
B
】
Deep groove ball bearing 6305
◆
Tools: Bearing tooling 6305.
◆
Lay the box
【
A
】
flat, with the inner cavity facing
upwards, and press into the bearing
【
B
】
.
A
A
B
B
Install the parking mechanism
【
A
】
Push rod guide seat
【
B
】
Parking arm return torsion spring
【
C
】
Hexagon socket pan head stepped bolt
【
D
】
Parking arm
【
E
】
Parking arm shaft
【
F
】
Left box
◆
Tool: T40 inner plum blossom sleeve.
◆
Put
【
A
】
into the left box
【
F
】
,
【
B
】
install it as
shown by the dotted line in the fi gure, apply thread
glue to the bolt
【
C
】
and lock it, install it into the
shaft
【
E
】
and then install
【
D
】
, The torsion
spring
【
B
】
the moment arm snaps into the dotted
E
E
C
C
D
D
A
A
B
B
F
F
Install the bearing plate of the left box body
【
A
】
Countershaft bearing pressure plate
【
B
】
Triaxial bearing press plate
【
C
】
Bolt M6×16
【
D
】
Left box
◆
Tool: 8mm sleeve.
◆
Apply thread glue to the connecting surface of the
left box
【
D
】
and bolt
【
C
】
, and lock the pressure
plates
【
A
】
and
【
B
】
in the direction shown in
Figure B.
Bolt M6×16
12N·m
(1.22kgf·m,8.86ft·lb)
(1.22kgf·m,8.86ft·lb)
B
B
C
C
A
A
D
D
