13 - 28
VEHICLE BODY AND FRAME
Front axle disassembly
◆ Carefully remove the front axle from the lower part of
the frame (the removal process may require you to
rotate and move the front axle)
◆
To install the front axle, follow the reverse procedure
◆ Remove the bolt D of the front axle box body.
◆ Remove the mounting bolts (hexagon flange bolts
M8×90) and nuts (type 2 non-metallic insert hexagon
flange locking nuts M8) of the front axle upper
bracket assembly B. Remove the upper bracket
assembly B of the front axle.
!
After removing the upper bracket assembly B of the
front axle, reinstall the front axle box bolt D.
To Next Page
