Appendix 1 Parameter table
Appendix 183
Group
Parameter
Number
Name
Setting Range
Default
Page
00-15
P.78
Prevent
forward/reverse
rotation selection
0: Forward/reverse rotation are both permitted.
0
59
1: Prevent reverse rotation (Giving reverse signal
decelerates and stops the motor).
2: Prevent forward rotation (Giving forward signal
decelerates and stops the motor).
00-16
P.79
Operation mode
selection
0: “PU mode”, “external mode” and “Jog mode” are
interchangeable.
0
59
1: “PU mode” and “JOG mode” are interchangeable.
2: “External mode” only
3: “Communication mode” only
4: “Combined mode 1”
5: Combined mode 2
6: Combined mode 3
7: Combined mode 4
8: Combined mode 5
00-17
P.97
Second target
frequency
selection
0: Frequency set by built-in keypad
0
59
1: Frequency set by RS485 communication
2: Frequency set by analog input
00-19
P.35
Communication
mode selection
0: In communication mode, run signal and frequency is
given by communication.
0
59
1: In communication mode, run signal and frequency is
given by external signal.
00-21
P.300
Motor control
mode selection
0: Induction motor V/F control
0
60
1:Reserved
2:Induction motor simple vector control
00-23
P.186
Motor types
selection
0: Normal Duty (ND), on fan and pump duty type
1
60
1: Heavy Duty (HD), apply to other duties
00-24
P.189
50Hz/60Hz switch
selection
0: Frequency related parameter default value is 60Hz.
0
61
1: Frequency related parameter default value is 50Hz.
1
00-25
P.990
Parameter display
mode setting
0: Parameter is displayed in group mode
0
61
1: Parameter is displayed in sequence P mode
01-00
P.1
Maximum
frequency
0.0001-02P.18Hz
120.00Hz
64
01-01
P.2
Minimum
frequency
0120.00Hz
0.00Hz
64
01-02
P.18
High-speed
maximum
frequency
01-00P.1)~650.00Hz
120.00Hz
64
01-03
P.3
Base frequency
50Hz system setting: 0650.00Hz
50.00Hz
65
60Hz system setting: 0650.00Hz
60.00Hz
01-04
P.19
Base voltage
01000.0V
99999
65
99999Change according to the input voltage
