Shihlin electric SC3 Series User Manual

Appendix 1 Parameter table
Appendix 190
Group
Parameter
Number
Name
Setting Range
Default
Page
04-27
P.101
Programmed operation mode
speed 1 operating time
0～6000.0s
0.0s
102
04-28
P.102
Programmed operation mode
speed 2 operating time
0～6000.0s
0.0s
102
04-29
P.103
Programmed operation mode
speed 3 operating time
0～6000.0s
0.0s
102
04-30
P.104
Programmed operation mode
speed 4 operating time
0～6000.0s
0.0s
102
04-31
P.105
Programmed operation mode
speed 5 operating time
0～6000.0s
0.0s
102
04-32
P.106
Programmed operation mode
speed 6 operating time
0～6000.0s
0.0s
102
04-33
P.107
Programmed operation mode
speed 7 operating time
0～6000.0s
0.0s
102
04-34
P.108
Programmed operation mode
speed 8 operating time
0～6000.0s
0.0s
103
04-35
P.111
Programmed operation mode
speed 1 Acc/Dec time
0～600.00s/0～6000.0s
0.00s
103
04-36
P.112
Programmed operation mode
speed 2 Acc/Dec time
0～600.00s/0～6000.0s
0.00s
103
04-37
P.113
Programmed operation mode
speed 3 Acc/Dec time
0～600.00s/0～6000.0s
0.00s
103
04-38
P.114
Programmed operation mode
speed 4 Acc/Dec time
0～600.00s/0～6000.0s
0.00s
103
04-39
P.115
Programmed operation mode
speed 5 Acc/Dec time
0～600.00s/0～6000.0s
0.00s
103
04-40
P.116
Programmed operation mode
speed 6 Acc/Dec time
0～600.00s/0～6000.0s
0.00s
103
04-41
P.117
Programmed operation mode
speed 7 Acc/Dec time
0～600.00s/0～6000.0s
0.00s
103
04-42
P.118
Programmed operation mode
speed 8 Acc/Dec time
0～600.00s/0～6000.0s
0.00s
102
05-00
P.301
Motor specifications automatic
measurement
0: Off
0
105
1: Induction motor specifications automatic
measurement (Run motor to measure)
2: Induction motor specifications automatic
measurement (Don’t run motor to measure)
3: Induction motor specifications automatic
measurement (Measure when operating)
05-01
P.302
Motor rated power
0～160.00kW
0.00kW
107
05-02
P.303
Motor poles
0～256
4
107
05-03
P.304
Motor rated voltage
0～510V
380V/440V
107
220V
05-04
P.305
Motor rated frequency
50Hz system：0～650.00Hz
50.00Hz
107
60Hz system：0～650.00Hz
60.00Hz
