Shihlin electric SC3 Series User Manual

Appendix 1 Parameter table
Appendix 191
Group
Parameter
Number
Name
Setting Range
Default
Page
05-05
P.306
Motor rated current
0~500.0A
According
to kw
107
05-06
P.307
Motor rated rotation speed
50Hz system：0～65000r/min
1410r/min
107
60Hz system：0～65000r/min
1710r/min
05-07
P.308
IM Motor excitation current
0~500.00A
According
to kw
107
05-08
P.309
IM motor stator resistance
0～99.98Ω：
According
to kw
107
06-00
P.9
Electronic thermal relay
capacity
0~500.00A
0.00A
110
06-01
P.22
Stall prevention operation level
0～250.0%
150.0%
111
06-02
P.23
Stall prevention operation level
correction factor
0～200.0%
99999
111
99999: Stall prevention operation level is the
setting value of 06-01(P.22).
06-03
P.66
Stall prevention operation
reduction starting frequency
50Hz system:0～650.00Hz
50.00Hz
111
60Hz system:0～650.00Hz
60.00Hz
06-05
P.30
Regenerative brake selection
0: Brake duty is fixed at 3%, parameter
06-06(P.70) will be off.
0
112
1: Brake duty is 06-06(P.70) value.
06-06
P.70
Special regenerative brake
duty
0～100.0%
0.0%
112
06-08
P.155
Over torque detection level
0～200.0%
0.0%
113
06-09
P.156
Over torque detection time
0～60.0s
1.0s
113
06-10
P.260
Action when detect over torque
0: OL2 alarm will not be reported after over
torque detection, and inverter keeps running.
1
113
1: OL2 alarm will be reported after over torque
detection, and inverter stops.
06-12
P.245
Cooling fan working mode
0：When running turn on the fan, after stop for 30
seconds turn off the fan.
1
114
1：When power on turn on the fan, after power off
turn off the fan.
2：When running and the heat sink temperature
exceeds 60℃ turn on the fan, under 40℃ turn
off the fan.
3：When the heat sink temperature exceeds 60℃
turn on the fan, under 40℃ turn off the fan.
06-13
P.281
Input phase loss protection
0: Off
0
114
1: When input phase loss, built-in keypad shows
IPF alarm and inverter stops
06-17
P.261
Maintenance alarm function
0: Off
0
114
1 ～ 9998day: Used to set the time for
maintenance alarm output signal
