SICK EtherCAT microScan3 User Manual

Table 2: Field types and their function
Protective
f
ield
Reference
contour field
Contour
detection
field
Collision pro‐
tection field
1)
Warning field
Safe switch off
(ac
cording to ISO
13849-1)
Yes (PL d) Yes (PL d) Yes (PL d) Yes (PL d) No
Max. scanning
range of the
safety laser scan‐
ner
Variant-
dependent:
4.0m
5.5m
9.0m
Variant-
dependent
:
4.0m
5.5m
9.0m
Variant-
dependent
:
4.0m
5.5m
9.0m
19.0m Variant-
dependent
:
40m
64m
Purpose Detection
and pr
otec‐
tion of people
Tamper pro‐
tection
e.g. door
monitoring
Detection of
an oncoming
industrial
truck in a nar‐
row aisle. Use
is only permit‐
ted in accord‐
ance with the
description in
this docu‐
ment, see
"Collision pro‐
tection in nar‐
row aisles",
page 57.
Functional
use (no
safety-rele‐
vant use)
1)
Available only for devices with the Pro performance package and a maximum protective field range of
9m.
Protective field
T
he protective field is the area in which the test object specified by the manufacturer
is detected by the electro-sensitive protective equipment (ESPE). As soon as the elec‐
tro-sensitive protective device detects an object in the protective field, it switches the
associated safety outputs to the OFF state. This signal can be passed to controllers
resulting in the dangerous state coming to an end, e.g. to stop the machine or the
vehicle.
PRODUCT DESCRIPTION 3
8025220/1L9Q/2023-08-14 | SICK O P E R A T I N G I N S T R U C T I O N S | microScan3 – EtherCAT®
17
Subject to change without notice

SICK EtherCAT microScan3 Specifications

General

Scanning angle	275°
Interfaces	EtherCAT
Protection class	IP65
Supply voltage	24 V DC
Resolution for protective field	30 mm
Operating voltage	24 V DC
Scanning range	5.5 m
Number of fields	128
Number of monitoring cases	128
Response time	30 ms
Operating temperature	0 °C to 50 °C
Field of application	Industrial safety
Light source	Infrared laser, 905 nm
Connection type	M12
Weight	1.2 kg
