Index Subindex Name Data type Value
6 Date UNSIGNED16 Date the current error occurred:
•
If t
ime synchronization is active and a UTC server
acts as the time master: days since January 1,
1972
•
If time synchronization is active and a device in the
Safety Designer project acts as the time master:
number of full 24-hour cycles of the time master
•
If time synchronization is not active: number of full
24-hour cycles since the device was switched on
7 Time UNSIGNED32 Time the current error occurred:
•
If time synchronization is active and a UTC server
acts as the time master: milliseconds since mid‐
night
•
If time synchronization is active and a device in the
Safety Designer project acts as the time master:
milliseconds since the start of the current 24-hour
cycle of the time master
•
If time synchronization is not active: milliseconds
since the start of the current 24-hour cycle since
switching on the device
8 Flags UNSIGNED16 Flags of the current error:
•
Bit 0: Reserved
•
Bit 1: Reserved
•
Bit 2: Time stamps are based on the network time.
(If the time stamps are based on the time since
device start-up, the value is 0.)
•
Bit 3: Time stamps are based on UTC. (If the time
stamps are based on an operating hour counter or
the time zone cannot be clearly determined, the
value is 0.)
•
Bit 4: Time stamps are exact. The value is 1 if the
deviation from the time of the network master is
less than the maximum deviation configured.
•
Bits 5 … 15: Reserved
9 Power On Count UNSIGNED32 Number of power-up processes until the current error
occurs
10 Error Type STRING Error type (e.g. C1)
11 Error Text STRING Error text as shown on the display
Table 56: Operation time (0x2110)
Index Subindex Name Data type Value
0x2,110 0 Number of
ent
ries
UNSIGNED8 7
1 Current Time UNSIGNED32 Current time:
•
If t
ime synchronization is active and a UTC server
acts as the time master: milliseconds since mid‐
night
•
If time synchronization is active and a device in the
Safety Designer project acts as the time master:
milliseconds since the start of the current 24-hour
cycle of the time master
•
If time synchronization is not active: milliseconds
since the start of the current 24-hour cycle since
switching on the device
13 T
ECHNICAL DATA
182
O P E R A T I N G I N S T R U C T I O N S | microScan3 – EtherCAT® 8025220/1L9Q/2023-08-14 | SICK
Subject to change without notice
