Index Subindex Name Data type Value
2 Current Date UNSIGNED16 Current date:
•
If t
ime synchronization is active and a UTC server
acts as the time master: days since January 1,
1972
•
If time synchronization is active and a device in the
Safety Designer project acts as the time master:
number of full 24-hour cycles of the time master
•
If time synchronization is not active: number of full
24-hour cycles since the device was switched on
3 Start Time UNSIGNED32 Time at device start-up:
•
If time synchronization is active and a UTC server
acts as the time master: milliseconds since mid‐
night
•
If time synchronization is active and a device in the
Safety Designer project acts as the time master:
milliseconds since the start of the current 24-hour
cycle of the time master
•
If time synchronization is not active: 0
4 Start Date UNSIGNED16 Date at device start-up:
•
If time synchronization is active and a UTC server
acts as the time master: days since January 1,
1972
•
If time synchronization is active and a device in the
Safety Designer project acts as the time master:
number of full 24-hour cycles of the time master
•
If time synchronization is not active: 0
5 Power On Count UNSIGNED32 Number of power-up processes
6 Flags UNSIGNED16
•
Bit 0: T
ime stamps are based on the network time.
(If the time stamps are based on the time since
device start-up, the value is 0.)
•
Bit 1: Time stamps are based on UTC. (If the time
stamps are based on an operating hour counter or
the time zone cannot be clearly determined, the
value is 0.)
•
Bit 2: Time stamps are exact. The value is 1 if the
deviation from the time of the network master is
less than the maximum deviation configured.
7 Operation
Hour
s
UNSIGNED32 Operating hours of the device
Table 57: Config info (0x2,120)
Index Subindex Name Data type Value
0x2,120 0 Number of
ent
ries
UNSIGNED8 10
1 Device Name STRING Device name as configured in Safety Designer
2 Application
N
ame
STRING Application name as configured in Safety Designer
3 Project Name STRING Project name as configured in Safety Designer
4 User Name STRING User name as configured in Safety Designer
5 Modification
T
ime
ARRAY of BYTE Time of last change to the configuration:
•
Bytes 0, 1: Date (days since January 1, 1972)
•
Bytes 2, 3: Reserved
•
Bytes 4 … 7: Time (milliseconds since midnight)
TECHNICAL DATA 13
8025220/1L9Q/2023-08-14 | SICK O P E R A T I N G I N S T R U C T I O N S | microScan3 – EtherCAT®
183
Subject to change without notice
