Index Subindex Name Data type Value
6 Transfer Time ARRAY of BYTE Time of last transfer of the configuration to the device:
•
B
ytes 0, 1: Date (days since January 1, 1972)
•
Bytes 2, 3: Reserved
•
Bytes 4 … 7: Time (milliseconds since midnight)
7 Reserved UNSIGNED32 Reserved
8 Application
Checksum
Checksum (function)
9 Overall Check‐
sum
Checksum (function and network)
10 Integrity Hash Lower-level identification number of the checksums
Table 58: Device Info (0x2,130)
Index Subindex Name Data type Value
0x2,130 0 Number of
ent
ries
UNSIGNED8 12
1 Package Serial
N
umber
UNSIGNED32 Serial number (device with system plug)
2 Package Order
Number
STRING Part number (device with system plug)
3 Device Serial
Number
UNSIGNED32 Serial number (device without system plug)
4 Device Order
Number
STRING Part number (device without system plug)
5 Sysplug Serial
N
umber
UNSIGNED32 Serial number (system plug)
6 Sysplug Order
Number
STRING Part number (system plug)
7 Firmware Ver‐
sion
Current firmware version
8 Current Config
S
et Version
Functionality of the configuration
9 Highest Config
Set Version
Functional scope of the device
10 Reserved UNSIGNED8 Reserved
11 Device Status UNSIGNED8 Device status
•
0: unc
lear device status
•
1: device start
•
2: service mode (e.g. optics cover calibration)
•
3: normal operation
•
4: device is waiting (e.g. for communication partner
or input signal)
•
5: maintenance recommended (e.g. contamination
warning)
•
6: maintenance required (e.g. configuration incom‐
patible)
•
7: correctable error (e.g. configuration error, network
error)
•
8: serious error
13 TECHNICAL DATA
184
O P E R A T I N G I N S T R U C T I O N S | microScan3 – EtherCAT® 8025220/1L9Q/2023-08-14 | SICK
Subject to change without notice
